Focus Beam LED

New Product
Focus Beam LED main unit photo Focus Beam LED rear unit photo Focus Beam LED FX photo Focus Beam LED FX photo Focus Beam LED FX photo Focus Beam LED Angle Omega Bracket Focus Beam LED Accessories Focus Beam LED angle Focus Beam LED straight on shot Focus Beam LED beam and frost filter Focus Beam LED fx Focus Beam LED 8-facet circular prism and 6-facet linear prism Focus Beam LED GOBOs photo Focus Beam LED Color Wheel photo
SKU: FOC369 | UPC: 818651026337

80W LED Beam moving head with a sharp 2.5-degree beam, motorized focus, two prims wheels and a built-in frost filter for wash effects.

Advantage Points: 1330

Where to Buy

Enter your zip code below to find this product at a retailer near you!

Product Description

Details

Available now from ADJ USA • $1329.99

The Focus Beam LED, a complimentary fixture to the other Focus Series moving heads, uses a powerful 80W LED engine to produce a powerful, 7400K, 2.5-degree beam from an advanced optical system. This fixture features motorized focus, two prism effects (rotatable 8-facet Circular and rotatable 6-facet Linear), and it has a built-in in frost filter for wash effects.

There are a variety of control options on the Focus Beam LED such as: DMX & RDM protocol, a variety of dimming modes, fine pan and fine tilt options, and adjustable gamma and LED refresh rate settings. There is an on-board function display with 5 touch buttons making it easy to dial in custom settings.

The Focus Beam LED offers 13 dichroic colors plus white, and has 15 fixed GOBOs plus open and a GOBO shake effect.

There is a convenient USB port on the rear panel used to update firmware. The fixture has locking Seetronic In/Out connections to daisy chain power, and 3-pin DMX In/Out to link data. The fixture is compact and lightweight suitable for fixed installations or temporary, mobile event applications.

Click here to read the Focus Beam LED press release.

Specifications

Specifications

Light Source:

• 80W Cool White LED Engine

• 2.5° Beam Angle

• Color Temperature: 7400K

• 50,000 Hour Average LED Life



Features:

• Control Protocol: DMX & RDM

• DMX Modes: 2 (16 & 18)

• Dim Modes: 6 Presets (Standard, Stage, TV, Architectural, Theatre & Stage 2)

• Dim Speed control (0.1~10 Seconds)

• Dimming: 0 - 100%

• Strobe & pulse control

• Motorized Focus

• Linear Frost 0-100% (Wash effect)

• 2 Prisms: 6 & 8 Facet, Indexable and Rotatable

• USB firmware update port

• Adjustable LED Refresh Rates (900~25k Hz)

• Adjustable Gamma Settings (1.0-2.8)

• With Wired Digital Communication Network

• Display: Touch display with 5-button touch menu



Color Wheel:

• 13 dichroic colors + white



GOBO Wheel:

• Metal wheel with 15 fixed GOBOs + Open

• GOBO shake effect



Prism Wheel:

• Prism Wheel 1: Rotatable 8-facet Circular

• Prism Wheel 2: Rotatable 6-facet Linear

• Prism Indexing with overlay feature



Control:

• Control Modes: DMX512, RDM & Stand Alone Internal Programs

• 2 DMX Channel Modes: 16 & 18 channels

• 16-Bit Pan, Tilt & Dimmer control


Connections:

• DMX Connections: 3-pin Locking XLR In & Out

• Power Connections: Seetronic Locking Power In & Out


Pan/Tilt:

• Pan & Pan Fine: 630 degrees

• Tilt & Tilt Fine: 270 degrees


Electrical:

• Multi-voltage operation: AC 100-240V, 50-60Hz (Auto Sensing)

• Maximum Power Consumption: 136W @ 120V

• Daisy chain: 15 units @ 120V; 30 units @ 230V


Dimensions & Weight:

• Dimensions (LxWxH):  10.96" x 6.85" x 17.61" / 278x174x447mm

• Weight: 27 lbs. (12.25 kg)



What’s Included:

• 2x Omega Brackets

• 1x Seetronic Power Locking Power Cable

Videos

Videos

Downloads

Downloads

The following downloads are available for this product:

Title Description
Focus Beam LED User Manual User Manual Download

FAQs

Frequently Asked Questions

Please see our frequently asked questions below. Please feel free to send us your questions by clicking here.

There are no FAQ's for Focus Beam LED
