XSP-8A

This item is discontinued

The XSP-8A powered speaker boasts a 15", 2-way active loudspeaker and a 400W bi-amplifier system encased in a lightweight cabinet. It features a 1.75" compression driver, time-aligned crossover, XLR and RCA balanced inputs, a built-in mixer, and an ABS nylon fiber cabinet with handle and full grill.
UPC: 640282000390SKU: XSP-8A

XSP-8A

 American Audio designed the XSP-8A speaker for use in both portable and permanently installed systems. The speaker includes a pole-mount slot and rubber feet on the bottom for portable applications. Rigging points on the top, bottom, and rear are provided and flight installations.  The XSP-15A by American Audio is a two-way active loudspeaker encased in a light weight cabinet. This speaker has been designed to be used as both a portable and a permanently installed unit.The XSP-15A's built-in power amplifier provides 400W of clean bi-amped power for plenty of output, and the unit has a time-aligned crossover to ensure the clearest possible sound for your program material. The 15" woofer is designed for high output, and the 1" high frequency driver is mounted to a 90° x 50° lens for clean and even dispersion.The XSP-15A features two each 1/4" and XLR microphone inputs, RCA and XLR line inputs, each with independent level control, and 1/4" and XLR line output to feed the signal to an additional powered speaker or subwoofer. Bass and treble controls are also included to tailor the overall sound to your specific taste or venue.

Specifications

  • 8-inch, 2-way Powered Speaker
  • 100W built-in Bi-amplifier system
  • Time Aligned Crossover
  • ABS nylon fiber cabinet with handle
  • Flyable or Stand Mountable
  • Full grille
  • XLR Mic/Line input with Volume Control
  • Dimensions (LxWxH): 11.5” x 9” x 16.5” / 290x230x420mm
  • Weight: 18 lbs. / 9 kg.
SPEAKER SPECIFICATIONS:
  • Frequency Response: 20Hz - 20KHz
  • Crossover: 3.3k
  • Nominal Dispersion: 90 x 50 (HXV)
AMPLIFIER SPECIFICATIONS:
  • Power consumption: 12 Watts
  • Line: -20dB(100mV)
  • Microphone: -40dB(10mV)
  • Output Sensitivity: 97.4 ± 2dB/m/w

Downloads

Cut sheet

User manual

XSP-8A Parts & Service

Our XSP-8A Parts and Support page is your hub for technical support for your product. Here you’ll find support docs, service resources, and replacement parts specifically matched to your XSP-8A. You can also use this area to plan future maintenance, extending the life of your investment and minimizing downtime.

XSP-8A Parts & Service
