Inno Spot LED WiFLY

(Discontinued)
SKU: INN333 | UPC: 819730011084
The ADJ Inno Spot LED WiFLY is a compact intelligent Moving Head with a bright 50-Watt LED engine. It features 6 rotating replaceable gobos, 8 colors plus white, and separate gobo/color wheels. The wireless transmission range is up to 500 feet open line of sight. The Inno Spot LED WiFLY may be controlled via Sound Activation with it’s own built-in programs, a DMX Controller, or the ADJ UC3 easy-to-use controller.
Advantage Points: 700

Where to Buy

Enter your zip code below to find this product at a retailer near you!

Product Description

Details

Now with ADJ’s WiFLY Wireless DMX technology, ,the ADJ Inno Spot LED WiFLY is a compact intelligent Moving Head with a bright 50-Watt LED engine. It features 6 rotating replaceable gobos, 8 colors plus white, and separate gobo/color wheels. It’s hard edge beam is similar to a traditional halogen or discharge lighting effect with a fraction of the power draw (93W) or the hassle of changing out light bulbs (LED source rated at 50,000 hours).

 Users may control the Inno Spot LED WiFLY wireless with ADJ’s WiFLY Transceiver or other WiFLY controllers. The wireless transmission range is up to 500 feet open line of sight.

 The Inno Spot LED WiFLY is lightweight and small in size making it extremely mobile, and can be set up by any size entertainer. It’s feature packed with exciting built-in light shows when used in Sound Active or linked in Master/Slave mode, offers 10 DMX channels, 4-Button LED DMX menu, Dimming, Shutter and Gobo Shake effect. The Inno Spot LED WiFLY may be controlled via Sound Activation with it’s own built-in programs, a DMX Controller, or the ADJ UC3 easy-to-use controller.


Specifications

Specifications

  • High output Intelligent Moving Head with a bright white LED source, with wireless DMX
  • Compatible with all ADJ’s WiFLY wireless DMX products
  • 5-Bar WiFLY signal strength indicator on rear panel
  • 8 colors + white
  • 6 rotating, replaceable gobos + spot
  • Separate Color & Gobo Wheels
  • Gobo scroll mode
  • 10 DMX Channels
  • 4 Operational modes: DMX Controlled, WiFLY DMX, Show Mode or Sound Active
  • 4-Button menu system digital display making it easy to navigate
  • Built-in lighting programs
  • Gobo Shake effect
  • 3-facet prism
  • Gobo size: 23.8mm (19mm viewable / 0.2mm thickness)
    540° pan / 270° tilt (8-bit)
  • Manual Focus
  • Shutter: Pulse effect; random strobe slow to fast
  • Dimming: 0% - 100%
  • Fan Cooled
  • 17-degree beam angle
  • 3-pin XLR chassis mount connectors for DMX linking
  • Stepper motors with micro stepping
  • Compatible with the ADJ UC3 Series easy-to-use controllers (sold Separately)
  • Includes built-in ADJ’s WiFly Transceiver Wireless DMX
  • Runs extremely cool! - NO Duty Cycles! – Run all night!
  • Power consumption: 99W total (All LED's @ Full)
  • Switchable voltage: (120V/60Hz or 230V/50Hz)
  • Light Source: 50W White LED source (Rated at approximately 50,000 hours)
  • Lux @ 3M: 2250 Lux
  • Dimensions (LxWxH): 8.75” x 8” x 12.75” / 221 x 202 x 320mm
  • Weight: 15 lbs. / 6.8 kgs.

Videos

Videos

Downloads

Downloads

The following downloads are available for this product:

Title Description
Inno Spot LED WiFly User Manual Download
Into Spot LED WiFly Photometrics Download

FAQs

Frequently Asked Questions

Please see our frequently asked questions below. Please feel free to send us your questions by clicking here.

Is there an ADJ case or bag that can fit a pair of Inno Spot LED Wiflys?

Hello,



Yes there is. It's called ADJ tough bag. This bag was originally made for our inno spot pro but it will fit two wifly inno spots in it. Let me know if you have any further questions.





I have a pair of the American DJ Inno Spot (50w) and a pair of the Inno Spot with Wifly. I am having trouble getting all 4 to work in master/slave together. Is this possible? I'm trying to avoig making programs with a DMX controller.. Please advise. Thanks!

They may not work identicle since the programs are diffrent. Try using the older unit as a master and the newer one as a slave.
