DMX Operator 192

(Discontinued)
ADJ's DMX Operator 192 controls up to 192 DMX channels. It is MIDI controllable and has a built-in microphone. It also records up to 12 programmable chases with fade time and speed control. The 8 individual faders provide easy programmability for intelligent lighting or dimmer packs.
Advantage Points: 300

Where to Buy

Enter your zip code below to find this product at a retailer near you!

Product Description

Details

ADJ's DMX Operator Controller is an expansion so the simple to use DMX Operator. It has 12 individual fixture channels which allows you to control up to 12 separate intelligent lights wuth up to 16 DMX channels per fixture and any fixtures with less than 16 DMX channels can be combined on one channel which gives you 192 DMX channels to do what ever you want with.

With ADJ's DMX Operator Controller you can record up to 12 programmable chases with fade times and different speeds. The 8 individual faders provided you with easy programmability for the intelligent light or dimmer packs that you may have. ADJ also included a USB input for your convince to save your programs and settings or use it to power an USB work light. Also for your convenience we have included an assignable joystick and LCD display. You can attach a fog machine as well (only compatible with select ADJ foggers).

Specifications

Specifications

  • Assignable Joystick
  • Pan/Tilt Fine button
  • 192 DMX channels
  • 12 Fixtures- 16 DMX channels each
  • 30 programmable scene banks- 240 total programmable scenes
  • 12 programmable chases
  • 8 control faders
  • Speed and Fade faders
  • USB input for optional "USB Lite" or "USB MemStick"
  • Built-in microphone for sound trigger
  • Line level RCA audio input for music trigger
  • MIDI input for scene, chase or blackout trigger
  • LCD display
  • DMX polarity switch
  • Power failure memory
  • Tap Sync button for chase speed over-ride
  • Fog Machine input and trigger button (compatible with select ADJ foggers)
  • RS-232 input
  • Blackout button

Videos

Videos

Downloads

Downloads

The following downloads are available for this product:

Title Description
DMX Operator 192 User Manual Download
DMX Operator 192 Set Up Rev1 Download

FAQs

Frequently Asked Questions

Please see our frequently asked questions below. Please feel free to send us your questions by clicking here.

There is a DMX/MIDI switch on the back of my Operator 192 that is not described in any documentation. What does it do?

I am sending this to service for a reply.

Folks, just purchaced 6 china made 230w 7r beam lights 16 channel. can I run these on the operator 192 W/toggle without a problem and do I need a download for these lights to run. Thanks for any effort. BUCK

There is no menu for lights on this controller. You need to follow the DMX instructions for you fixture to control the movement or colors etc.

Is it possible to program the 192 operator from a computer software?

You may not program this controller with a computer.
