WiFLY QA5 IP

UPC#: 819730012296
Advantage Points: 320
Redemption Points: 6400
SKU
WIF462
The ADJ WiFLY QA5 IP is an IP65 outdoor rated compact Wash Fixture with ADJ’s WiFLY wireless DMX built-in. It offers the power of 5x 5-Watt RGBA Quad LEDs (Red, Green, Blue & Amber) to create rich hues and smooth color mixing for stage or wall washing. This fixture uses LEDs rated at 50,000 hours with a maximum power draw of 35W.

Where to Buy

Enter your zip code below to find this product at a retailer near you!

  • IP65, Outdoor Rated, par fixture with five Quad RGBA LEDs (4-in-1 Red, Green, Blue & Amber LEDs)
  • Built-in WiFLY wireless DMX: compatible with ADJ’s WiFLY Transceiver (sold separately)
  • Creates no RGBA shadows
  • Compatible with ADJ RFC wireless remote control (sold separately)
  • 5 DMX Channel modes: 4, 5, 6, 10 or 11 channel modes
  • 7 Operational modes: Manual Color; Color Change; Color Jumping; Color Dreaming: Auto (Program Run); WiFLY and DMX Controlled
  • 64 built-in Color Macros
  • LED pulse and strobe effect
  • Flicker Free Operation
  • Refresh Rate: 1.44KHz
  • Electronic Dimming: 0 - 100%
  • Beam angle: 40-degree
  • Linkable via 3-pin IP cable (In/Out)
  • With Wired Digital Communication Network
  • 4-button DMX menu display on rear panel
  • Dual bracket yoke allows fixture to be hung or set on the ground
  • 4-Pin Power AC IN/OUT outlets on rear to daisy chain power (up to 15 units)
  • Run all night – No duty cycle
  • LED Source: 5x 5-Watt QUAD LEDs (4-in-1 RGBA- Red, Green, Blue & Amber LEDs, rated at approximately 50,000 hrs)
  • Light Output: 990 LUX @2M; 228 @4M (40-degree beam)
  • Power Draw: 35W total (All LED's @ Full On)
  • Multi-voltage operation: AC 100-240V, 50/60Hz
  • Dimensions (LxWxH): 10” x 7.5” x 12” / 250 x 190 x 300mm
  • Weight: 10 lbs. / 4.2 kg.

Videos

Downloads

The following downloads are available for this product:

Title Description
WiFly QA5 IP User Manual (Rev. 9/15) User Manual (Rev. 9/15) Download
WiFly QA5 IP User Manual User Manual Download
Wifly QA5 IP Photometric IES Files Photometric IES Files Download
Wifly QA5 IP Photometric Test Reports Photometric Test Reports Download
The ADJ WiFLY QA5 IP is an IP65 outdoor rated compact Wash Fixture with ADJ’s WiFLY wireless DMX built-in.It offers the power of 5x 5-Watt RGBA Quad LEDs (Red, Green, Blue & Amber) to create rich hues and smooth color mixing for stage or wall washing. ADJ’s WiFLY Transceiver will communicate up to 500 feet (open line of sight) with the WiFLY QA5 IP.

 This fixture uses LEDs rated at 50,000 hours with a maximum power draw of 35W. DMX addressing may also be changed by the unit’s 4-button LED display, or controlled by a DMX Controller by DMX cabling or via ADJ’s stand alone WiFLY Transceiver.
