VioSCAN LED

UPC#: 640282001816
Advantage Points: 350
Redemption Points: 7000
SKU
VSC594

Where to Buy

Enter your zip code below to find this product at a retailer near you!

  • LED DMX-512 flat mirrored scanner with sharp Red, Green, Blue & White Beams
  • Bright 10W RGBW Quad LED
  • 2 DMX Channel Modes (1 Channel or 5 Channels)
  • 4-Button menu system LED Display making it easy to navigate
  • 3 Operational modes: DMX controller, Primary/Secondary & Sound Active
  • Exciting built-in lighting programs
  • Pan/Tilt Inversion Mode: when using 4 scanners in Primary/Secondary Scanner 1 & 3 sync opposite Scanner 2 & 4
  • Manual focusing lens
  • Dimming: 0-100%
  • Strobe effect
  • Beam angle: 30-degrees
  • X/Y mirror movement
  • 1.8 degree Stepper motors with micro stepping
  • Hanging Bracket + safety hook included
  • Compatible with American DJ UC3 Series easy-to-use controllers (sold Separately)
  • Run all night – No duty cycle – Unit stay cool all night
  • No cooling fan required - Very little maintenance needed
  • IEC AC IN/OUT on rear to daisy chain power
  • Extreme long lifetime of the LED (30,000 hr. rating)
  • LUX @ 3M: Red = 288; Green = 713; Blue = 32; White = 958
  • Power consumption: 34W max
  • Multi-voltage operation: AC 100V~240V 50/60Hz- IEC socket
  • Dimensions (LxWxH): 16.5"x6.5"x6.75" / 420x161x172mm
  • Weight: 10 lbs. / 4.2kg.

Videos

Downloads

The following downloads are available for this product:

Title Description
VioSCAN LED User Manual Download
The ADJ VioScan LED is a high output, low maintenance Moonflower effect with a smooth, stepper motor driven scanning mirror. It’s 10-watt Quad LED source produces dozens of red, green, blue and white (RGBW) beams from it’s exciting built-in programs.

The VioScan LED has three operational modes (DMX, Primary/Secondary, Sound Active), has a Pan/Tilt Inversion Mode and a long-life 30,000 hour rated LED. This unit offers many useful features not found on other effect lighting in this price range, such as: 4-button DMX menu, 1.8 degree stepper motors, IEC AC IN/OUT on rear to daisy chain power, ADJ UC3 easy-to-use controller compatibility and a safety hook.
