Sweeper Beam Quad LED

Name: Sweeper Beam Quad LED
Brand: ADJ
SKU: SWE199
Availability: InStock

This item is discontinued

This product has been discontinued.

UPC: 819730010568

SKU: SWE199

Sweeper Beam Quad LED

$0.00

Sweeper Beam Quad LED

This product has been discontinued.

The ADJ Sweeper Beam Quad LED creates exciting lighting effects with its quick sweeping beams and it’s 8-Zone RGBW LED chasing, pulsing and strobing LEDs. This unique fixture features 8x 8-Watt bright, Quad LEDs with a narrow 3.4 degrees beam angle, 4 DMX Channel modes and a 4-Channel LED DMX menu.

The Sweeper Beam LED may be controlled via it’s own built-in programs, a DMX Controller or the easy-to-use UC3 Controller. Best when used in multiples, the Sweeper Beam LED is designed for stages, nightclubs and mobile entertainers.

Specifications

• Unique lighting fixture with quick sweeping narrow beams combined with an 8-Zone LED chase

• 8x 8-Watt RGBW LEDs

• 4-Button DMX LED Display

• 3 Operating Modes - Show Mode; Sound Active; DMX Controlled

• Stand Alone or Primary/Secondary Configuration

• 4 DMX Channel modes (1, 6, 35 or 39 channels)

• DMX-512 Protocol

• With Wired Digital Communication Network

• Electronic Dimming: 0 - 100%

• Includes exciting sound activate built-in programs

• LED pulse strobe effect

• 270 degree X-axis tilt from smooth Stepper Motors

• Extremely Long Life (50,000 hr. rated)

• Beam angle: 3.4-degrees

• Runs extremely cool! - NO Duty Cycles! – Run all night!

• Includes mounting brackets to mount on a wall or set on the ground

• Safety hook on rear panel

• Very low power consumption - connect more units in a single circuit

• IEC AC IN/OUT on rear to daisy chain power (up to 4 Sweeper Beam Quad LED’s @ 120V and 7 Sweeper Beam Quad LED’s @ 230V )

• Compatible with ADJ UC3 Series easy-to-use controllers (sold Separately)

• Power Consumption: 81W maximum

• Multi-voltage operation: AC 100-240V 50/60Hz- IEC socket

• Power cable length: 1.5 meter (IEC)

• Dimensions (LxWxH): 38.5”x 3”x 5.25” / 973 x 73 x 132mm

• Weight: 14 lbs. / 6.3 kg.

• cETLus approved (Control #400358)

Downloads

User manual

Sweeper Beam Quad LED User Manual

Sweeper Beam Quad LED Parts & Service

Our Sweeper Beam Quad LED Parts and Support page is your hub for technical support for your product. Here you’ll find support docs, service resources, and replacement parts specifically matched to your Sweeper Beam Quad LED. You can also use this area to plan future maintenance, extending the life of your investment and minimizing downtime.

Sweeper Beam Quad LED Parts & Service
