Inno Spot LED

(Discontinued)
A lightweight Compact Intelligent Moving Head, the ADJ Inno Spot LED is perfect for any venue. Comes with 8 colors + Spot, 7 rotating and replaceable gobos, and a 19 degree beam angle. Made with the highest quality plastics and components, you are sure to get a long life with the ADJ Inno Spot LED.
Advantage Points: 600

Where to Buy

Enter your zip code below to find this product at a retailer near you!

Product Description

Details

The ADJ Inno Spot LED is a lightweight, powerful fixture that is compact and extremely mobile. The Inno Spot LED offers professional features and a reliable performance that is evident in ADJ's other professional lighting products. The 8 colors + Spot, 7 rotating and replaceable gobos, 19 degree beam angle and the separate color and gobo wheels let you customize your light show for any venue or event. Get more area coverage and stunning visual effects with its 3 facet prism. Made with the highest quality plastics and components, you are sure to get a long useful life out of this fixture. With its built in light shows the Inno Spot LED has capabilities to be used in Sound Active mode or linked in Master/Slave mode. This light has no duty cycle so feel comfortable running all night long and with its LED light source, the ADJ Inno Spot stays cool all night. The Inno Spot LED is compatible with the ADJ UC3 Series easy to use controllers as an additional control option. Let your guests dance the night away in the lights of the Inno Spot LED Today!

Specifications

Specifications

  •  High output Intelligent Moving Head with a bright 50W white LED source
  •  8 colors + white
  •  6 rotating, replaceable gobos + spot
  •  Separate Color & Gobo Wheels
  •  Gobo scroll mode
  •  17-degree beam angle
  •  Auto X-Y repositioning
  •  10 DMX Channels
  •  3 Operational modes: DMX-512, Master/Slave & Sound Active
  •  4-Button menu system LED Display making it easy to navigate
  •  Built-in lighting programs
  •  Gobo Shake effect
  •  3-facet prism
  •  Gobo size: 23.8mm (19mm viewable / 0.2mm thickness)
  •  540° pan / 270° tilt (8-bit)
  •  Manual Focus
  •  Shutter: Pulse effect; random strobe slow to fast
  •  Dimming: 0% - 100%
  •  Fan Cooled
  •  Stepper motors with micro stepping
  •  Compatible with the ADJ UC3 Series easy-to-use controllers (sold Separately)
  •  Runs extremely cool! - NO Duty Cycles! – Run all night!
  • PWM (Pulse Width Modulation): 0.4K
  • Strobe Rate: 0.4-25HZ
  •  Power consumption: 93W
  • Power Cable Length: 1.5M (IEC)
  •  Switchable voltage: (120V/60Hz or 230V/50Hz)
  •  LED Source: 50W White LED source (50,000 hour rated)
  • Light Output: 5250 LUX @2M; 1240 LUX @4M (17-degree beam)
  •  Dimensions (LxWxH): 9.75” x 8.25” x 11.25” / 242 x 205.8 x 284.6mm
  •  Weight: 15 lbs. / 6.5 kgs.
  • ETL Approved

Videos

Videos

Downloads

Downloads

The following downloads are available for this product:

Title Description
Inno Spot LED Cut Sheet Download
Into Spot LED Photometrics Download
Inno Spot LED User Manual Download

FAQs

Frequently Asked Questions

Please see our frequently asked questions below. Please feel free to send us your questions by clicking here.

How do I make the innoSpotLED stop rotating and use like a spot light?

Use a DMX operator controller to control X and Y Movement.

None of the shows work and I only used it once

Please contact our service department. Call 323-582-2650 and ask for Service Department.

Can you access all the features of the Inno Spot LED fr the 4 buttom menu? EX. I would like to project one of the Gobos to a wall with a specific color and ni movement.

No. What you are looking for requires some sort of DMX controller. Either software or hard board.

Help! I am preparing for a big gig, and cannot get my inno-spot LED to respond to DMX! How do I get it out of Show mode? The instructions manual doesn't specifically say! I set my DMX channel, but it is still going thru show mode! Also, when I plug this unit into my DMX chain, some of my other lights start to malfunction, and stop responding to my DMX controller!

Please contact service at AMERICAN DJ DUPPLY,or ernie@americandj.com.

Hi, I have two adj inno spot LED Wiflys and two adj inno pocket spots. I want to know if there is a way to set them up in master/slave mode. Thanks in advance.

hello Joe,

Thank you for reaching out to us. Unfortunately, those two lights cannot master slave with each outher. They are two diffrent lights with diffrent built in programs. Let me know if you have any further questions.

Thanks,
