18P Hex

UPC#: 819730019950
Advantage Points: 470
Redemption Points: 9400
SKU
HEX686
All-metal Par with eighteen 12-Watt Hex (6-IN-1) LEDs, 63 built-in Color Macros, locking power in and out connections and heavy duty metal construction with gel frame included.

Where to Buy

Enter your zip code below to find this product at a retailer near you!

Features:

• 18x 12-Watt Hex LEDs

• 63 built-iin Color Macros

• Locking power in and out connections

• Heavy duty metal construction with Gel Frame included

• ETL Approved

• With Wired Digital Communication Network


Optical:

• Light Source: 18 x 12-Watt Hex (RGBAW + UV) LEDs

• LED Life Expectancy: 50,000 Hrs

• Refresh Rate: 3.6KHz

• 25-degree beam angle


Technical Features:

• 63 Built In Color Macros

• 5 Operational Modes: Manual Color; Color Fade; Auto Program; Sound Active, and DMX modes.

• 4-button Digital Display for easy navigation

• Electronic Dimming 0 – 100%

• Flicker Free

• Gel Frame Included

• Includes a scissor yoke to be hung, or set on the ground


Connections:

• Power Input: Locking Power IN socket

• Power Pass through: Locking Power OUT socket (Daisy chain up to 7 units @120V, 16 units @ 230V)

• Control: 3-pin and 5pin In/Out DMX


Control:

• 4 DMX Channel Modes: 6, 7, 8 and 12

• Compatible with Dotz Par RF (Sold Separately)

• On Board control

• With Wired Digital Communication Network

• DMX, RDM (Remote Device Management)


Electrical:

• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)


Physical:

• Dimensions (LxWxH): 11.96” x 6.88” x 13” / 304 x 174.8 x 330.4mm

• Weight: 12.9 lbs / 5.9 kg.

• Metal Black Housing


Certifications:

• IP 30: Dry area, No liquids

• cETLus Approved (Control #4010765)


Whats Included:

• (1) 1 Meter, Locking Power to Edison Cable

• (1) Gel Frame

• Owner’s Manual



Optional Accessories:

• Dotz Par RF (Remote Control)



Videos

Downloads

The following downloads are available for this product:

Title Description
18P Hex - Cut Sheet (Rev. Oct 2021) Cut Sheet Download
18P Hex - Cad Drawing Cad Drawing Download
18P Hex - Photometric IES Files Photometric IES Files Download
18P Hex - Photometric Test Reports Photometric Test Reports Download
18P Hex - User Manual User Manual Download
18P Hex - Vectorworks Symbol Vectorworks Symbol Download

Available now from ADJ USA

The ADJ 18P Hex is an all metal, powerful LED Par fixture with 18x 12-Watt, 6-IN-1 HEX LEDs. Produces wide washes with smooth color mixing from 63 built-in color macros utilizing red, green, blue, amber, white and UV LEDs. Not only is this LED Par great for lighting stages, but with its patent pending, intelligently designed, power and DMX connectors, it’s great for uplighting large venue.

18P HEX professional features include: 4 DMX modes (6, 7, 8 and 12), 5 operational modes, 5 dimming curves, flicker free operation and a 4-Button DMX menu with digital display. Daisy-chain up to 4 units (110V) or 8 units (240V) together via the fixtures built-in locking power in and out connections.

The 18P HEX is compatible with the Dotz Par RF easy-to-use wireless RF remote (Sold Separately). Alternatively the fixture may be operated via a DMX controller or the units built-in programs.  It comes with a metal gel frame in which a beam diffuser (sold separately) may be used to soften the beam.

Learn more about the 18P HEX in our product spotlight article: CLICK HERE
